Specifications
Camera
Image Sensor
1/4 type CCD with Exwave HAD technology
Number of Effective Pixels
NTSC: Approx. 0.38 Megapixels PAL: Approx. 0.44 Megapixels
Signal System
PAL
Minimum Illumination (50 IRE)
Color : 0.8 lx (XDNR ON, VE ON, Slow Shutter OFF, 50 IRE) B/W : 0.09 lx (XDNR ON, VE ON, Slow Shutter OFF, 50 IRE)
Minimum Illumination (30 IRE)
Color: 0.40 lx (F1.6, AGC ON, 1/50 s) B/W: 0.050 lx (F1.6, AGC ON, 1/50 s)
S/N Ratio (Gain 0 dB)
More than 50 dB
Gain
Auto / Manual (-3 to +28 dB)
Shutter Speed
1 s to 1/10000 s
Exposure Control
Auto, Full auto, Shutter-priority, Iris-priority, Manual, EV compensation, Backlight compensation
White Balance
Auto, Indoor, Outdoor, One-push WB, ATW, Manual
Lens
Auto-focus zoom lens
Powered Zoom
Yes
Easy Zoom
No
Zoom Ratio
Optical zoom 36x
Powered Focus
Horizontal Viewing Angle
57.8°to 1.7°
Focal Length
f = 3.4 mm to 122.4 mm
F-Number
F1.6 (wide), F4.5 (tele)
Minimum Object Distance
320 mm (wide) to 1500 mm (tele)
Pan/Tilt/Rotation Angle (manual)
360° endless rotation/ 210°
Pan Speed
400 degrees/s (max.)
Tilt Speed
Number of Preset Positions
256
Number of Tour Programs
5 preset tours, 4 shadow tours, 16 presets per one preset tour
IR Illuminator
Camera Features
Day/Night
True D/N
Wide-D
DynaView
Tone Correction
VE (VE)
Noise Reduction
XDNR
Image Stabilizer
Vandal Resistant
IK10
Ingress Protection
IP66
Video
Resolution
720 x 576, 640 x 480, 384 x 288, 320 x 240
Compression Format
H.264, MPEG-4, JPEG
Maximum Frame Rate
H.264/MPEG-4/JPEG : 25 fps (720 x 576)
Multi streaming Capability
Triple streaming*1
Number of Clients
10
Intelligent Video/Audio Analytics
Analytics Architecture
DEPA
Intelligent Motion Detection
Audio
G.711/G.726
System Requirements
Operating System
Microsoft Windows XP Windows Vista (32 bit) Windows 7 (32 bit)
Processor
CPU: Pentium4 2.4 GHz, Intel Core2 Duo1.8 GHz or higher
Memory
1 GB or more
Web Browser
Microsoft Internet Explorer Ver. 6.0, Ver. 7.0, Ver. 8.0 Firefox Ver. 3.5 (plug-in free viewer only) Safari Ver. 4.0 (plug-in free viewer only) Google Chrome Ver.4.0 (plug-in free viewer only)
Network
Protocols
IPv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client/server), SMTP, DHCP, DNC, NTP, RTP/RTCP, RTSP, SNMP(MIB-2)
Number of IP Address/Mac ADDRESS
1
ONVIF Conformance
Profile S
Wireless Network
Yes (with optional SNCA-CFW5)
Authentication
IEEE 802.1X
Interface
Analog Video Output
Composite video (1.0 Vp-p) 530 TV lines
Microphone Input
Mini jack (monaural), MIC IN/LINE IN: 2.2kΩ, 2.45 V DC plug-in power
Line Input
Mini jack (monaural)
Line Output
Mini jack (monaural), Max output level : 1 Vms
Network Port
10BASE-T/ 100BASE-TX (RJ-45)
Alarm Input (Sensor Input)
x4
Alarm Output
x2
Serial Interface
RS-232C, RS-422/RS-485 (PELCO D protocol)
Card Slots
CF card x 1
USB Slots
General
Power Requirements
AC 24 V
Power Consumption
78 W max.
Operating Temperature
-40 to +50℃ -40 to +122°F
Storage Temperature
-20℃ to +60℃ -4°F to +140°F
Operating Humidity
20 to 90%
Storage Humidity
20 to 95%
Dimensions (W x H x D)*2
φ238 x 344 mm φ9 3/8 x 13 5/8 inches
Mass
Approx. 4.3 kg Approx. 9 lb 8 oz
Safety Regulations
UL2044, FCC(Class A) ICES-003 Class A Digital Device IEC60950-1 EN55022(A)+EN55024+EN50130-4 JATE Technical standard (LAN), VCCI Class A AN/NZS CISPR22
Supplied Accessories
CD-ROM (User's Guide, SNC toolbox) (1) Top sunshade coupling (1) Belt (1) Bolts Cables Waterproof caps Warranty card (1) Installation Manual (1)
Notes
*1
Triple streaming (Any combination with JPEG/MPEG-4/H.264, including multiple streams of the same format)
*2
The values for dimensions are approximate.
