CAMERA
|
|
Image Sensor
|
1/3 type CMOS (primary color flter)
|
Number of
Effective Pixels
|
Approx. 1.3 million pixels
|
|
Scanning Method
|
Progressive
|
|
Lens
|
5x optical zoom (20x digital zoom) auto focus lens
|
|
Focal Length
|
17.7 (W) – 88.5 mm (T)
|
|
F-number
|
F1.8 (W) – F2.4 (T)
|
|
Viewing Angle
|
For 16:9 aspect ratios:
Horizontal: 15.6° (W) – 3.2° (T)
Vertical: 8.8° (W) – 1.8° (T)
For 4:3 aspect ratios
Horizontal: 15.6° (W) – 3.2° (T)
Vertical: 11.7° (W) – 2.4° (T)
|
|
Day/Night Switch
|
Auto/Day Mode/Night Mode
|
Min. Subject
Illumination
|
Day Mode (colour): 0.04 lux
Night Mode (monochrome): 0.002 lux
- (F1.8, 1/30 sec., SSC off, 50IRE)
|
|
Focus
|
Auto/One-shot AF/Manual/Fixed at infnity
|
Shooting Distance
(from front of lens)
|
Day Mode: 3.0 m (9.8 ft.) – infnity (W), 5.0 m (16.4 ft.) – infnity (T)
Night Mode: 3.0 m (9.8 ft.) – infnity (W), 5.0 m (16.4 ft.) – infnity (T)
|
|
Shutter Speed
|
1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/50, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000,
1/2000, 1/4000, 1/8000, 1/10000, 1/16000 sec.
|
|
Exposure
|
Auto/Auto (Flickerless)/Auto (Shutter-priority AE)/Auto (Aperture-priority
AE)/Manual (Shutter Speed, Aperture, Gain)
|
|
White Balance
|
Auto/Light Source/Manual
Light Source: Daylight Fluorescent/White Fluorescent/Warm
Fluorescent/Mercury Lamp/Sodium Lamp/Halogen Lamp
Manual: One-shot WB/R Gain/B Gain
|
|
Metering Mode
|
Center-Weighted/Average/Spot
|
Exposure
Compensation
|
9 levels
|
Smart Shade
Control
|
Auto/Manual/Disable, Auto: 3 levels, Manual: 7 levels
– Brightens shaded areas of a video
|
|
Haze Compensation
|
Auto/Manual/Disable, Auto: 3 levels, Manual: 7 levels
|
|
AGC Limit
|
6 levels
|
|
Image Stabilizer
|
2 levels (digital)
|
Motion-Adaptive
NR
|
Available
|
|
Clear IR Mode
|
Available
|
|
Pan Angle Range
|
348° (±174°)
|
|
Tilt Angle Range
|
105° (ceiling-mounted position: -90° – +15°)
– When the horizontal direction of the camera is 0°
|
|
Moving Speed
|
Pan: Max. 300°/sec.
Tilt: Max. 300°/sec.
|
|
SERVER
|
Video
Compression
Method
|
JPEG, H.264
|
|
Video Size
|
JPEG, H.264: 1280 x 720, 640 x 360, 320 x 180
1280 x 960, 640 x 480, 320 x 240
|
|
Video Quality
|
JPEG, H.264: 10 levels
|
|
Frame Rate
|
JPEG: 0.1 – 30 fps
H.264: 1/2/3/5/6/10/15/30 fps
– Values represent streaming performance from the camera.
– The frame rate may be reduced due to Viewer computer’s specs, the
number of clients accessing at the same time, network loads, video
quality setting, type or movement of the subject or other reasons.
Maximum frame rate when streaming:
H.264(1) (1280 x 720) and H.264(2) (1280 x 720) simultaneously: 15 fps
H.264(1) (1280 x 960) and H.264(2) (1280 x 960) simultaneously: 15 fps
|
|
I-Frame Interval
|
0.5/1/1.5/2/3/4/5 sec.
|
Simultaneous
Client Access
|
Max. 30 Clients + 1 Admin Client
– H.264: Max. 10 Clients
|
|
Bit Rate Control
|
Target Bit Rate: 64/128/256/384/512/768/1024/1536/2048/3072/4096/
6144/8192/10240/12288/14336/16384 kbps
|
ADSR: Area
specifc Data Size
Reduction
|
Number of Specifed Areas: Max. 8 areas
Data Size Reduction Level: 3 levels
|
|
Security
|
Camera Control: Administrator, Authorized user, Guest user (level of
control varies depending on user)
Access Control: User authority (user name and password), Host Access
Restrictions (IPv4, IPv6)
IEEE802.1X: EAP-MD5, EAP-TLS, EAP-TTLS, EAP-PEAP
Encrypted Communications: SSL/TLS, IPsec
|
|
Protocol
|
IPv4, IPv6, TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS,
AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS,
IPsec, ONVIF, WV-HTTP (Canon proprietary)
|
Audio
Compression
Method
|
G.711 μ-law (64 kbps)
|
Audio
Communication
Method
|
Full-duplex (two-way)/half-duplex
– Echo cancellation function compliant
RTP, Sound Transfer Protocol by Canon
|
